AirPilot H743.
Autopilot-class, three firmware stacks.
36 x 36 mm flight controller for professional integrator, OEM, and prosumer platforms. Heterogeneous dual IMU pair, CAN-FD, three redundant power inputs. Same STM32H7 family as AirBrain H743, Pixhawk-standard core ports instead of the compact Betaflight-aligned layout.
Pre-order open. Pricing on request, no fixed retail price yet.
480 MHz Cortex-M7 with double-precision FPU, 2 MB program flash.
TDK ICM-45686 primary, Bosch BMI088 secondary. Two vendors, two MEMS technologies, redundancy-aware autopilots fail over cleanly.
VBAT direct, Pixhawk-standard POWER1, 4-pin POWER2 backup. Any one rail can fail or be hot-swapped without interrupting flight.
AEC-Q100 automotive-qualified transceiver, on-board 120 ohm termination, removable for daisy-chain topologies.
36 x 36 mm board, Pixhawk-standard GPS, telemetry, and POWER1 ports. Different form factor from the compact 20 x 20 mm AirBrain H743.
Every broken-out pin gets a JST connector plus a labelled solder pad next to it. Same signal, two ways in.
Reserve your AirPilot H743.
Pre-orders are confirmed by email with the latest delivery window. Volume and OEM enquiries welcome.
AirPilot H743
Pre-order open . pricing on request
